WELCOME

Abyss Fire Designs specialize in the design of fully hydraulic, calculated sprinkler systems.


We know how vital it is to have well designed fire protection systems, and thanks to our expertise, we ensure that you are provided with drawings for a system that is designed to highly professional standards. Currently operating on a nationwide basis throughout South Africa, with plans for expansion, our team of designers and office staff provide a professional and efficient service for any customer in need of life-saving solutions.


We design water systems, mist systems, wet and dry riser systems and pumps and tanks for both commercial and residential properties.


With over 11 years’ experience in the fire protection industry, our designers work tirelessly to provide you, our valued clients, with drawings for the latest sprinkler systems.


about us

All our design engineers are fully qualified, and we have invested heavily in the latest hydraulic calculation software to enable our design team to work to their full potential.



Full CAD designs and hydraulic calculations are included in our design only package. These clearly show the sprinkler head positions, dimensions and other relevant requirements to help on site installation. We are pleased to be the preferred fire sprinkler designer for many fire-protection companies. We also work very closely with architects, property developers and other design consultants.



As required by building control we will provide all the hydraulic calculations needed as part of our design. If a tank and pump system is required, we will also calculate this and provide sizings to suit. Each category of goods will be recognized and carried out according to the design density of each hazard. An official cutting list will be issued once signed off by the approved parties, and each contractor will fabricate as per cutting list provided to them.



















                         alexandre barnard
                         FOUNDER & DIRECTOR

bio:

My love and passion for designing and engineering started when I attended technical drawing classes in high school. I knew then that this was what I wanted to do with my life. I then went on to study draughting and AutoCAD at Sedibeng College in South Africa.


Getting a life-saving, hydraulic calculated drawing into the hands of my clients is my calling. I love to empower and push myself (and my team) to be capable of designing bigger and better more technical projects.


I take my own personal development very seriously!


After many years of working in the industry, I soon realised that there is a need for contract draughtsmen and thus, Abyss Fire Designs was born in January 2020.


We at Abyss, pride ourselves on attention to detail, with the clients’ needs and requirements at the forefront of EVERYTHING we do. We value the relationships we have with our clients, mainly built on trust and discretion. Very often, when working closely with our clients, we can make suggestions for different construction lay-outs for any future projects, to allow for a more efficient design, thus saving our clients valuable time and money.



  • OUR STANDARDS
asib


sans

OUR standards N

home1-1
nfpa
FM GLOBAL

OUR designs & portfolio :

  • High rise buildings


__
  • Ordinary hazard systems



__
  • high HAZARD SYSTEMS


__
  • Water supplies pump room and tanks



__
  • SPrinkler valve chambers


__
  • Deluge valves for conveyors, tank cooling and bund foam systems


__
  • Transformers


__
  • Block plans


__
RACKING & ESFR



__
  • DRY PIPE SYSTEMS


__
  • SITE MEASURE &DESIGN


__
CANUTE FHS & AUTOCAD
ENABLED



__

customer TestimonialS

Belfa Fire :

“Abyss Fire thank you very much for helping us working late and pushing out the drawings, not only was the drawings easy to read on site, but the installation process fit like a glove..”

Eagle Fire

“Abyss fire we will definitely come back for more. Thanks for the quality drawings”

Lotus Civils & Fire

“Abyss Fire is the best and only fire draugting company that we will be dealing with as it’s the most cost effective design methods

Pro Secure

“Abyss Fire is always so helpful and friendly and always eager to help out with advice doesn’t matter what time of day we call”.
